From as-built drawings to analytics-ready layout data.
I digitize solar PV DC layouts into GIS-ready inverter, combiner, and string polygons — the spatial foundation for KPI mapping, underperformance analysis, and monitoring platform digital twin onboarding.
Services
Three levels of spatial detail — start with a pilot site, then roll across your portfolio. All work is human-reviewed and delivered ready for QGIS, ArcGIS, or your BI stack.
Inverter polygons
Digitized inverter block polygons with standardized IDs and labels — the foundation for inverter-level KPI mapping and spatial plant views.
Inverter + combiner polygons
Polygons for both inverters and combiner boxes, with parent-child hierarchy fields so you can roll up metrics or pinpoint issues at combiner level.
Inverter + combiner + string areas
Where drawings support it, string-level polygons or row groups are added and linked to their combiner and inverter for deep-dive fault analysis.
Monitoring platform digital twin onboarding
Polygon deliverables can be structured to align with your monitoring platform's hierarchy model — reducing onboarding friction and speeding up your digital twin build-out. I have hands-on experience with the major enterprise solar monitoring platforms. Ask about this in your quote request.
How it works
A straightforward human-in-the-loop process: you provide your documentation, I do the digitizing and QA, and you receive clean layers ready to drop into your stack.
Send your drawings
Share your as-built PDFs or CAD files, combiner/inverter schedules, and any naming conventions you use.
Digitize & label
I create polygons for inverters, combiners, and strings (where visible) and assign clean, consistent IDs and labels.
Review & refine
You review a draft layer and QA log, resolving any ambiguous or missing labels before the final delivery.
Receive your data
Final GeoJSON / shapefile layers, a CSV asset register, and QA notes — ready for KPI mapping, dashboards, or platform onboarding.
Deliverables
All packages use a consistent schema so you can reuse the data across tools, platforms, and over time as your portfolio grows.
| File | Description |
|---|---|
polygons.geojson / .shp |
Feature layers for inverter, combiner, and (where available) string polygons. Attributes include asset_id, asset_type, inv_id, cmb_id, str_id, label_text, qa_status, and source_doc. |
asset_register.csv |
Tabular list of all features and fields — ready for joins with SCADA tags, monitoring platform hierarchies, or KPI tables in R, Python, or Power BI. |
qa_log.csv |
All ambiguous or unresolved items, plus every assumption made during digitization. Full audit trail for your records. |
Pricing
Pricing depends on inverter count, drawing quality, and required detail level. Volume discounts apply for portfolio work across multiple sites.
| Site size | Typical assumptions | Typical range |
|---|---|---|
| Small plant | ≈10 inverters, 50–100 combiners | €1,200 – €2,000 |
| Medium plant | ≈25 inverters, 200–300 combiners | €2,500 – €4,500 |
| Large plant | ≥50 inverters, ≥500 combiners + string detail | €5,000 – €9,000 |
Send your as-built set (or a sample drawing) and I'll respond with a fixed price per site — no open-ended hourly billing.
